Description
The rugged pump lower construction with Severe Duty rods and cylinders reduces downtime and extends the interval between repairs. The simple construction makes service and repair fast and easy. The efficient hydraulic powered piston makes these pumps the ideal choice for factory and outdoor mobile use, even at below freezing temperatures.
- Clean, quiet operation with no airborne contamination
- Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
- Up to three times more energy efficient than comparable compressed air systems
- Reduce routine maintenance and cut repairs time in half of comparable pump lowers
- Eliminate downtime without ice build-up
UPC Product: 00633955129405Family Code: FAMCPPUnit of Measure: EAHeight: 16.8 IN |42.672 CMLength: 61.2 IN |155.448 CMWidth: 15.6 IN |39.624 CMVolume: 9.282 FT3 |.263 M3Chargeable Weight: 240 LBS | 108.86 KG
Technical Specifications
| Type | Hydraulic Piston Pump |
|---|---|
| Application | Supply |
| Compatible Material | Waterborne, Solventborne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish |
| Fluid Inlet Size (in) | 2 |
| Fluid Inlet Size (mm) | 50.8 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 1-1/2 |
| Fluid Outlet Size (mm) | 38.1 |
| Fluid Outlet Thread Gender | Male |
| Fluid Outlet Thread Type | NPT |
| Fluid Section Type | 2-Ball |
| Material | Carbon Steel |
| Maximum Flow Rate (GPM) | 9.2 |
| Maximum Flow Rate (L/min) | 34.83 |
| Maximum Hydraulic Fluid Inlet Pressure (bar) | 103 |
| Maximum Hydraulic Fluid Inlet Pressure (kPa) | 10300 |
| Maximum Hydraulic Fluid Inlet Pressure (psi) | 1500 |
| Maximum Intermittent Cycle Rate (CPM) | 60 |
| Maximum Operating Temperature (°C) | 66 |
| Maximum Operating Temperature (°F) | 150 |
| Maximum Working Pressure (bar) | 138 |
| Maximum Working Pressure (kPa) | 13800 |
| Maximum Working Pressure (psi) | 2000 |
| Model | Viscount |
| Portable | Non-Portable |
| Pump Ratio | 20:1 |
| Series | II |
| Wetted Material | Carbon Steel |
| Maximum Working Pressure (MPa) | 13.8 |
