Speedhut 4″ 120 mph EV Speedometer Gauge (FAE4-S1-EV)

Description

The Speedhut 4″ 120 mph EV Speedometer Gauge (FAE4-S1-EV) is specifically engineered to provide accurate, real-time monitoring of your electric vehicle’s power consumption. Designed for seamless integration with your EV’s CAN-Bus system (operating at a 500K baud rate), this gauge delivers precise kilowatt readings, enabling you to understand and optimize your vehicle’s energy usage for peak performance and efficiency.

KEY FEATURES AND BENEFITS:

• This 4-inch (100mm mounting hole) gauge: Offers a clear and immediate display of your EV’s power, ranging from -50 to 300 kW.
• CAN-Bus connectivity: Connects directly to your vehicle’s CAN-Bus network, eliminating the need for additional sensors.
• Real-time monitoring: Accurately tracks power draw during acceleration, cruising, and regeneration.
• Driving habit insights: Provides valuable feedback on energy use and driving efficiency.
• Simple installation: Includes all necessary wiring harnesses for straightforward setup.

SPECIFICATIONS:

• Gauge Type: Power
• Signal Type: CAN-Bus (500K baud rate)
• Range: -50 to 300 kW
• Size: 4 inches (diameter)
• Hole Size: 3.93 inches (100mm)
• Included:
• 3 ft Power & Lighting Harness – for LED Lit Gauges and Clocks
• EV CAN Jumper Harness
• EV CAN Harness

HOW TO USE:

1. Locate the appropriate mounting location: Identify a suitable spot on your dashboard or instrument panel that can accommodate the 4-inch gauge and provides good visibility.
2. Drill the mounting hole: Using a 3.93-inch (100mm) hole saw, carefully create the opening for the gauge.
3. Connect the CAN-Bus harness: Attach the provided EV CAN Harness to your vehicle’s CAN-Bus network. Ensure proper connections as per your vehicle’s wiring diagram.
4. Connect the gauge to the CAN-Bus: Use the EV CAN Jumper Harness to link the gauge to the connected EV CAN Harness.
5. Connect the power and lighting harness: Attach the 3 ft Power & Lighting Harness to the gauge and connect the power and ground wires to your vehicle’s electrical system (if applicable for backlighting).
6. Mount the gauge: Insert the gauge into the drilled hole and secure it using the appropriate mounting hardware (likely integrated into the gauge design).
7. Verify functionality: Turn on your vehicle and observe the gauge to ensure it is receiving and displaying power readings correctly.

BENEFITS OF USING THE SPEEDHUT 4″ 120 MPH EV SPEEDOMETER GAUGE (FAE4-S1-EV):

• Real-time power monitoring: Enables precise tracking of energy usage during various driving conditions.
• Efficiency optimization: Helps refine driving habits to potentially extend range and reduce energy waste.
• Power system diagnostics: Assists in monitoring the health and performance of your EV’s power system.
• Energy awareness: Enhances your understanding of consumption and regeneration dynamics.

FEATURES:

• Provides an immediate and clear visual representation of your EV’s power status.
• Communicates directly with your vehicle’s central computer system via CAN-Bus for unparalleled accuracy.
• Displays both power consumption (positive kW) and regenerative power (negative kW).
• Designed specifically for electric vehicles, ensuring compatibility and relevant data.
• Offers a straightforward installation process with the included wiring harnesses.
• Contributes to a greater understanding of your EV’s energy dynamics and efficiency.
• Compact 4-inch size allows for flexible mounting options within your vehicle.
