Jet EVS-1440B EVS Lathe w/ Taper Attachment & Collet Closer (311443)

Description

The Jet EVS-1440B EVS Lathe w/ Taper Attachment & Collet Closer (311443) is a versatile metal lathe designed for efficient and precise machining. Built with a robust construction and advanced features, this lathe is ideal for both professional and DIY workshops.

KEY FEATURES AND BENEFITS:

• Powerful Performance: The 3 HP motor delivers ample power for various metalworking tasks.
• Precision Machining: The D1-4 spindle, supported by class 7 tapered roller bearings, ensures accuracy and smooth operation.
• Versatility: Taper attachment and collet closer expand machining capabilities.
• User-Friendly: Electronic variable speed control, LED RPM readout, and ergonomic design enhance usability.
• Durable Construction: V-way bed design, Meehanite castings, and heavy-duty components provide long-lasting performance.

SPECIFICATIONS:

• Motor: 3 HP, 230/460 V, 3 Ph
• Spindle: D1-4, 1-1/2 in bore
• Swing: 14 in over bed, 9-1/16 in over cross slide
• Distance Between Centers: 40 in
• Spindle Speed: 40-2000 RPM
• Threads: 2-56 to 12 mm
• Feeds: 0.0016-0.0460 in/rev
• Dimensions: 68.5 x 28.3 x 50 in
• Weight: 1320 lbs (net), 1584 lbs (gross)

HOW TO USE:

• Set up the lathe: Securely mount the lathe on a stable, level surface. Connect to the power supply according to the manual.
• Prepare workpiece: Securely clamp the workpiece between the lathe centers or in a chuck.
• Adjust spindle speed: Select the appropriate spindle speed for the material and desired cutting conditions.
• Engage feed: Use the feed controls to advance the cutting tool into the workpiece at the desired rate.
• Operate cutting tool: Carefully manipulate the cutting tool to achieve the desired shape and dimensions.
• Monitor and adjust: Continuously monitor the cutting process and make adjustments as needed.

BENEFITS OF USING Jet EVS-1440B EVS Lathe w/ Taper Attachment & Collet Closer (311443):

• Increased productivity due to powerful motor and efficient operation.
• Precise and accurate machining results.
• Expanded capabilities with taper attachment and collet closer.
• User-friendly features for comfortable operation.
• Durable construction for long-term reliability.

FEATURES:

• Electronic variable speed control
• Two-speed gearbox
• V-way bed design
• Independent leadscrew and feed rod
• Compound and cross slide with backlash elimination
• Taper attachment
• Collet closer
• Electronic chuck key docking station
• Front removable chip tray
• Full length splash guard
• Integrated locking tool storage cabinet
• LED RPM readout
• Safety on/off switch
• Threading dial indicator
