Description
The Jet BDB-1340A Lathe w/ Newall NMS300 DRO and Collet Closer (321361) is a robust benchtop machine designed for precision metalworking. Equipped with a Newall NMS300 Digital Readout (DRO) and a collet closer, this lathe offers accuracy and efficiency in a compact package. Ideal for hobbyists and professionals alike.
KEY FEATURES AND BENEFITS:
- Newall NMS300 DRO: Provides precise measurements for accurate machining.
- Collet Closer: Ensures efficient workholding for various workpiece sizes.
- Enclosed Gearbox: Offers quiet operation and smooth performance.
- Fast Speed Changes: Versatile for different materials and applications.
- Metric Threading: Expand your machining capabilities with change gears.
- Gap Bed Design: Accommodates larger diameter workpieces.
- Tapered Roller Bearings: Ensures spindle stability and longevity.
SPECIFICATIONS:
- Swing Over Bed: 13 inches
- Distance Between Centers: 40 inches
- Spindle Bore: 1-3/8 inches
- Spindle Mount: D1-4
- Motor: 2 HP, 230V, 1Ph
- Threading Capacity: Metric and Inch
- Feed Rates: Adjustable for various materials
- Weight: 1175 lbs
HOW TO USE:
- Set Up: Secure the lathe to a sturdy workbench, ensuring level positioning. Connect to a power supply.
- Workpiece Mounting: Choose the appropriate chuck or collet based on workpiece size. Secure the workpiece tightly.
- Tool Selection: Select the correct cutting tool for the desired operation. Mount it securely in the tool post.
- Speed and Feed Adjustment: Set the spindle speed and feed rate according to the material and desired cutting parameters.
- Machining: Engage the feed or power feed to perform turning, facing, or threading operations.
- Coolant Application: Use coolant as needed to improve tool life and workpiece finish.
- Safety: Always wear appropriate safety gear, including eye protection and hearing protection.
BENEFITS OF USING Jet BDB-1340A Lathe w/ Newall NMS300 DRO and Collet Closer (321361):
- Precision Machining: Achieve accurate and repeatable results with the Newall DRO.
- Versatility: Handle a wide range of materials and workpiece sizes.
- Efficiency: Fast speed changes and smooth operation save time.
- Durability: Built to last with quality components and construction.
- Safety: Low voltage motor controls and enclosed gearbox enhance safety.
FEATURES:
- Direct Mount Scroll Chuck with Top Reversing Jaws: Provides secure clamping for various workpieces.
- Automatic Feeding and Threading Interlock: Ensures precise and safe operation.
- Carriage Mounted Spindle Control Lever: Allows for easy spindle control.
- Centers and Headstock Center Sleeves: Included for versatile workholding.
- Change Gears for Metric Threading: Expands threading capabilities.
- Helical Cut Headstock Gears: Enhances gear durability and performance.
- Independent Lead Screw and Feed Rod: Provides smooth and reliable feeding.
- Low Voltage Motor Controls: Improves safety and control.
- Precision Tapered Roller Bearings: Ensures spindle stability and longevity.
- Tailstock Offset for Taper Turning: Allows for precise taper turning operations.
- Tolerance Test Certificate Included: Verifies machine accuracy and quality.
