Description
IMER Koine 4 208V/60Hz 9 HP 3 Phase Pump (1106304) is designed for high-volume and efficient mixing and pumping of wall grouts and self-leveling underlayments. This pump is perfect for indoor applications due to its quiet operation and high-performance capabilities.
The IMER Koine 4 offers tremendous production with a robust 9 HP motor. It includes advanced features such as a dust grate with a vacuum port, gear-driven feed impeller, and a self-priming stainless steel water pump. This makes it ideal for large-scale projects that require reliable and consistent performance.
- Specifications and Dimensions
- Power: 208V/60Hz, 3 Phase
- Total machine power: 9 HP
- Mixing motor power: 7.5 HP
- Feeding impeller motor: 1 HP
- Water booster pump: 70 PSI boost
- Material flow rate: 140 cu ft/h
- Max. pumping distance: grouting/fireproofing 200 ft+
- Max. pumping distance: self-leveling 300 ft+
- Gearbox speed: 400 RPM
- Loading height: 35.5 in
- Dimensions (W x L x H): 29″ x 47″ x 61.5″
- Weight: 510 lbs
- Key Features and Benefits
- High-volume mixing and pumping for large-scale projects
- Quiet operation, ideal for indoor use
- Advanced dust control with vacuum port
- Robust and durable construction
- Integrated tool storage for convenience
- Versatile application for wall grouts and self-leveling underlayments
