Description
HHIP 3906-2339 4.3″ Tilting Rotary Table is a precision tool engineered for versatile metalworking applications. This tilting rotary table allows machinists to accurately position workpieces at various angles for milling, drilling, and CNC operations. Its dual-axis adjustment enables both tilting and rotation, providing precise angular control for complex machining tasks.
Features:
- Dual-axis adjustment for tilting (0°–90°) and 360° rotation.
- Graduated worktable with 360° rotation and micro-collar steps of 2° for precise positioning.
- Made from high-quality hardened steel for durability and stability.
- 90:1 hardened and ground worm gear for smooth, accurate, and repeatable rotation.
- Can be mounted horizontally or vertically to suit different machining setups.
- Standard T-slot worktable for secure mounting and holding of workpieces.
- Micrometric adjustment screws enable fine angular positioning.
Benefits:
- Enables precise angular machining and indexing of workpieces.
- Enhances flexibility in setups with tilting and rotational capabilities.
- Durable construction ensures reliable performance over time.
- Ideal for milling, drilling, CNC operations, and precision fabrication.
Technical Specifications:
- Model: 3906-2339
- Table Diameter: 4.3″
- Tilting Range: 0°–90°
- Rotation Ratio: 90:1 worm gear
- Material: Hardened steel
- Graduations: Full 360° worktable
- Adjustment Increment: 2° micro-collar steps
- Mounting: Horizontal or vertical
