Description
Features
Mix and match pumps, reservoir and manifolds in any configuration to meet any application. Replace the pump or reservoir without disconnecting lubrication lines.
- Easy to standardize on components and reduce inventory
- Adjustable pump output for fast, convenient customizing
- Lubriquip part number 521-000-041
Specifications
UPC Product: 00633955351134 Family Code: FAMMPM Unit of Measure: EA Height: 6 IN |15.24 CM Length: 16.8 IN |42.672 CM Width: 6 IN |15.24 CM Volume: .35 FT3 |.01 M3 Chargeable Weight: 7.5 LBS | 3.4 KG
Technical Specifications
| Type | Pneumatic Piston Pump |
|---|---|
| Application | In-Plant Machinery |
| Compatible Material | Oil, Grease |
| Maximum Air Inlet Pressure (bar) | 10.34 |
| Maximum Air Inlet Pressure (kPa) | 1034 |
| Maximum Air Inlet Pressure (psi) | 150 |
| Maximum Cycle Rate (CPM) | 30 |
| Maximum Fluid Output Pressure (psi) | 3500 |
| Maximum NLGI Grade | #2 |
| Maximum Working Pressure (bar) | 207 |
| Maximum Working Pressure (kPa) | 20680 |
| Maximum Working Pressure (psi) | 3000 |
| Model | Modu-Flo |
| Power Type | Pneumatic |
| Series | AL-50 |
| Compatible Metering Device | Series Progressive |
| Overall Depth (cm) | 8.1 |
| Overall Depth (in) | 3.188 |
| Overall Depth (mm) | 81 |
| Overall Height (cm) | 8.1 |
| Overall Height (in) | 3.188 |
| Overall Height (mm) | 81 |
| Overall Width (cm) | 32.5 |
| Overall Width (in) | 12.812 |
| Overall Width (mm) | 325 |
| Maximum Working Pressure (MPa) | 31 |
| maximum_fluid_output_pressure_bar | 241 |
