Description
Features
You can’t afford down time, especially when your shop is small and your work force depends on equipment performance. The Mini Fire-Ball 225 is an engineered design with fewer moving parts, which means less wear out, and reduced downtime and more profit for your business.
The Mini Fire-Ball 225 50:1 is perfect for medium pressure, low volume grease applications.
- Durable – Thick cast aluminum air motor housing offers unmatched durability.
- Fewer Repairs – Fewer moving parts in the air motor assembly means less downtime and low repair cost.
- Extended Seal Life – In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
- Superior Sealing – Non-metallic poppet valves offer positive sealing performance, even with contaminated “dirty” air environments for long life without repair.
- Reduced Icing – Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
- Corrosion-Resistant – Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.
- Reduce Downtime – Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
Specifications
UPC Product: 00633955168305 Family Code: FAMPPF Unit of Measure: EA Height: 0 IN |0 CM Length: 0 IN |0 CM Width: 0 IN |0 CM Volume: 0 M3 |0 FT3 Chargeable Weight: 62.27 LBS | 28.25 KG
Technical Specifications
| Application | Industrial |
|---|---|
| Compatible Material | Grease |
| Fluid Outlet Size (cm) | 0.635 |
| Fluid Outlet Size (in) | 1/4 |
| Fluid Outlet Size (mm) | 6.35 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
| Includes | Mini Fireball 50:1 225Pump, Mini Fireball 50:1 225 Bomba, Hose and Fitting Kit, juego de manguera y conexiones, Cover, cubierta, Follow Plate, plato seguidor, Shim, espaciador |
| Maximum Working Pressure (bar) | 345 |
| Maximum Working Pressure (kPa) | 34500 |
| Maximum Working Pressure (psi) | 5000 |
| Motor Type | Pneumatic |
| Mount Location | Drum Mount |
| Series | 225 |
| Pump Ratio | 50:1 |
| Air Inlet Size (in) | 0.375 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Wetted Material | Steel, Urethane, Aluminum, Buna-N, Brass, Ethylene, Delrin |
| Fluid Inlet Type | Slotted, Ranurado |
| Pump Weight (lb) | 15 |
| Type | Piston Pump Package |
| Power Type | Pneumatic |
| Maximum Working Pressure (MPa) | 35 |
| Maximum Air Working Pressure | 8400 |
| Model | Mini Fire-Ball |
| Container Size (lb) | 400 |
