Description
Features
With its one piece design, Graco’s GL-32 grease injector systems are easy to design, fast to set up and allow you to add or subtract lube points without having to redesign your lubrication system. Easily handles up to NLGI #2 grease.
Accurate, reliable lubrication for every lube point on your machine
- Longer lasting seal design for trouble-free performance
- Precision-honed components for reliable operation in challenging environments
- Convenient front-mounted cycle pin indicator for quick confirmation that the injector is functioning properly
- Operating pressures from 83–241 bar (1200–3500 psi) for optimal performance with up to NLGI #2 grease
- Offered both as a stand-alone injector and replacement injector for manifold systems, allowing you to custom fit the injectors to your applications
- Adjustable output volume from 0.02–0.13 cm³ (.001–.008 in³) to custom fit the system to meet the needs of each lube point
Specifications
UPC Product: 00633955470477 Family Code: FAMMPM Unit of Measure: EA Height: 2.4 IN |6.096 CM Length: 6 IN |15.24 CM Width: 3.6 IN |9.144 CM Volume: .03 FT3 |.001 M3 Chargeable Weight: 0.313 LBS | 0.142 KG
Technical Specifications
| Adjustable | Adjustable |
|---|---|
| Compatible Material | Grease |
| Cycle Indicator | Visual Pin |
| Inlet Size (cm) | 0.635 |
| Inlet Size (in) | 1/4 |
| Inlet Size (mm) | 6.35 |
| Inlet Thread Type | NPT |
| Material | Carbon Steel |
| Maximum NLGI Grade | #2 |
| Maximum Working Pressure (bar) | 241 |
| Maximum Working Pressure (kPa) | 24100 |
| Maximum Working Pressure (psi) | 3500 |
| Outlet Size (cm) | 0.32 |
| Outlet Size (in) | 0.125 |
| Outlet Size (mm) | 3.2 |
| Type | Grease Injector |
| Compatible Metering Device | Single Line Parallel |
| Application | On-Road Vehicles, Off-Road Equipment |
| Maximum Working Pressure (MPa) | 24.1 |
| Model | GL-32 |
