FiTech 1000HP Oval Port EFI 4150 Flange Classic Gold (30-11-414)

Description

The FiTech 1000HP Oval Port EFI 4150 Flange Classic Gold (30-11-414) is designed to provide precise fuel delivery and engine management for high-performance Big Block Chevy engines with oval port cylinder heads. This system offers both self-tuning and user-tunable capabilities, allowing for optimized performance across various driving conditions. It supports up to 1000 horsepower when using gasoline and is compatible with a wide range of fuels including E85, alcohol, and methanol. This kit includes all the necessary components for a comprehensive EFI conversion, such as an ECM, injectors, sensors, and wiring harness.

KEY FEATURES AND BENEFITS:

• Provides multi-port fuel injection: For accurate fuel delivery.
• Supports up to 1000 horsepower: When using gasoline.
• Offers both self-tuning and user-tunable options.
• Compatible with various fuels: Including gasoline, E85, alcohol, and methanol.
• Includes all necessary sensors and wiring: For a complete installation.
• Features a 4.5-inch display: For user interface and monitoring.
• Designed for Big Block Chevy engines: With oval port cylinder heads.
• Includes intake manifold and 4150 flange throttle body.

SPECIFICATIONS:

• Maximum Horsepower (Gas): 1000 HP
• Injection Style: Multi-port
• Timing Control: Yes
• Power Adder Compatibility: Forced induction/Nitrous oxide
• ECM Included: Yes
• Self-Tuning: Yes
• User-Tunable: Yes
• Fuel Pump Included: No
• Metering Style: Speed density (Map-N) or speed throttle (Alpha-N)
• Intake Material: Aluminum
• Throttle Body Mounting Flange: 4-barrel square bore (4150)
• Airflow Rate: 1000 CFM
• Injector Size: 80 lbs/hr
• Compatibility: Big Block Chevy engines with standard deck height and oval port cylinder heads.

HOW TO USE:

• Preparation: Disconnect the battery and remove the existing intake manifold and carburetor.
• Installation: Install the FiTech intake manifold onto the engine, ensuring proper gasket placement.
• Throttle Body Mounting: Attach the FiTech throttle body to the intake manifold using the provided hardware.
• Fuel Rail and Injector Installation: Mount the fuel rails and install the injectors into the intake manifold.
• Sensor Installation: Install the MAP, IAT, TPS, and IAC sensors according to the provided instructions.
• Wiring Harness Connection: Connect the wiring harness to the sensors, injectors, and ECM, following the wiring diagram.
• Oxygen Sensor Installation: Install the oxygen sensor into the exhaust system.
• ECM Mounting: Mount the ECM in a suitable location within the engine compartment.
• Fuel System Setup: Install the required fuel pump and pressure regulator, connecting them to the fuel rails.
• Display Connection: Connect the 4.5-inch display to the ECM.
• Initial Setup: Power on the system and follow the on-screen instructions for initial setup and calibration.
• Fine Tuning: After initial setup, the user can fine-tune the system using the display or a laptop.

BENEFITS OF USING THE FITECH 1000HP OVAL PORT EFI 4150 FLANGE CLASSIC GOLD (30-11-414):

• Improved Fuel Economy: Enhanced engine performance.
• Precise Fuel Delivery: For optimal combustion.
• Reduced Emissions: Compared to traditional carburetors.
• Easy Installation: With self-tuning capabilities.
• Enhanced Engine Responsiveness: Improved drivability.
• Ability to Fine Tune: The engine for specific applications.

FEATURES:

• Gold finish cast aluminum throttle body.
• 80 lbs/hr fuel injectors.
• Complete wiring harness.
• Included 3-bar MAP sensor.
• Compatibility with multiple fuel types.
• 1000 CFM airflow rating.
• Ability to control timing.
