Description
Magnetically-operated sensing devices for sending system data to the controller or PLC.
-
Available in 115 VAC or 12-32 VDC
-
Available for all series progressive families to provide cycle rates up to 200 CPM
-
Pressure ratings up to 10,000 psi (690 bar)
-
Variety of electrical connections and voltages with or without LED indication
-
Select models available with UL and CSA approvals
UPC Product: 00633955337527 Family Code: FAMCPT Unit of Measure: EA Height: 2.25 IN |5.715 CM Length: 4.25 IN |10.795 CM Width: 5.95 IN |15.113 CM Volume: .033 FT3 |.001 M3 Chargeable Weight: .61 LBS | .28 KG
Technical Specifications
| Material | 303 Stainless Steel, Buna-N |
|---|---|
| Type | Field-Sensing Magnetic |
| Maximum Working Pressure (bar) | 241 |
| Maximum Working Pressure (kPa) | 24100 |
| Power Connection Type | 5-Pin BH Mini |
| Maximum Working Pressure (psi) | 3500 |
| Compatible Material | Oil, Grease |
| Amperage (A) | 2 |
| Maximum Working Pressure (MPa) | 24 |
