American Forge & Foundry 750Lb Cap Transmission Adapter Head (3165)

Description

The American Forge & Foundry 750Lb Cap Transmission Adapter Head (3165) is a highly practical and robust accessory designed to significantly enhance the functionality of your existing floor jack. This heavy-duty, hydraulic adapter converts compatible floor jacks into a specialized transmission jack, making the challenging tasks of removing and installing automobile transmissions, transfer cases, and differentials far more manageable and safer. With its substantial 750 lb capacity and precision tilt capabilities, the AFF 3165 provides the stability and control needed for accurate component alignment, whether you’re a professional mechanic or a dedicated automotive enthusiast.

KEY FEATURES AND BENEFITS:

• Converts Standard Floor Jacks: Transforms any AFF brand, Viking series, or other floor jacks with a 1-1/8” saddle stud into a dedicated transmission jack.
• High Load Capacity: Supports up to 750 lbs (0.38 Tons), making it suitable for a wide range of components.
• Precision Tilting: Offers 30° front tilt and 15° back tilt for precise alignment during installation and removal.
• Wide and Stable Saddle: Features a 19.5-inch wide saddle and 14 x 8-inch saddle spread for better stability.
• Heavy-Duty Construction: Engineered for rigorous workshop use with long-lasting durability.
• ASME PASE 2014 Safety Standard Compliant: Meets industry-standard safety requirements.

SPECIFICATIONS:

• Backward Tilt: 15°
• Capacity: 750 lb (0.38 tons)
• Standards: ASME PASE 2014 Safety Standard
• Duty Level: Heavy Duty
• Forward Tilt: 30°
• Operation: Hydraulic
• Type: Transmission Jacks
• Saddle Spread: 14 x 8 in.
• Side Tilt: 0°
• Weight: 28.6 lb

HOW TO USE:

1. Prepare the Floor Jack: Ensure your compatible AFF, Viking, or other floor jack with a 1-1/8” saddle stud is in good working condition.
2. Attach the Adapter Head: Remove the floor jack’s saddle and insert the adapter head’s stud into the saddle hole. Secure it according to the jack’s mechanism.
3. Position the Vehicle: Safely raise and support the vehicle on jack stands, providing ample clearance for transmission work.
4. Align the Adapter: Roll the jack with the attached adapter under the transmission. Position the component onto the saddle and center it securely.
5. Adjust Tilt as Needed: Use the tilt mechanism to achieve the necessary angle for alignment—30° front tilt or 15° back tilt.
6. Raise/Lower the Component: Use the jack’s hydraulic pump to raise or lower the transmission steadily while maintaining control and checking stability.
7. Secure After Installation: Once installed, lower the jack carefully and remove it from beneath the vehicle.

BENEFITS OF USING AMERICAN FORGE & FOUNDRY 750LB CAP TRANSMISSION ADAPTER HEAD (3165):

• Makes lifting and aligning transmissions and differentials easier and safer.
• Provides a stable and controlled lifting platform for heavy components.
• Eliminates the need for a separate transmission jack, saving space and cost.
• Precision tilt features assist in accurate alignment of parts and bolt patterns.
• Built to meet safety standards for peace of mind in workshop environments.

FEATURES:

• Compatible with AFF 350 series and Viking floor jacks.
• Fits jacks with a 1-1/8” saddle stud.
• Supports removal and installation of transmissions, differentials, and transfer cases.
• Includes a 19.5-inch wide saddle for secure support.
• Provides 30° front tilt for forward alignment.
• Provides 15° back tilt for rearward adjustments.
• Shipping weight is approximately 28 pounds.
