Description
Maintain consistent agitator speed, even with an empty drum
- Quick install, requires less than 1 minute to setup
- Prevents over agitation for shear sensitive and waterborne materials
- Saves energy by limiting agitator over speeding
- Prevents motor over speeding, extending lifetime
- Maintains constant set speed even as viscosity or drum levels change
- Provides closed-loop speed control for agitators
UPC Product: 00633955112605 Family Code: FAMQFP Unit of Measure: EA Height: 5 IN |12.7 CM Length: 8.4 IN |21.336 CM Width: 9.6 IN |24.384 CM Volume: .233 FT3 |.007 M3 Chargeable Weight: 2.429 LBS | 1.102 KG
Technical Specifications
| Air Inlet Size (cm) | 0.3175 |
|---|---|
| Air Inlet Size (in) | 1/8 |
| Air Inlet Size (mm) | 3.175 |
| Air Inlet Thread Type | NPT |
| For Use With | Air Drive Agitators |
| Maximum Air Inlet Pressure (bar) | 7 |
| Maximum Air Inlet Pressure (kPa) | 700 |
| Maximum Air Inlet Pressure (psi) | 100 |
| Maximum Speed (RPM) | 1000 |
| Minimum Air Inlet Pressure (bar) | 4.9 |
| Minimum Air Inlet Pressure (kPa) | 490 |
| Minimum Air Inlet Pressure (psi) | 70 |
| Minimum Speed (RPM) | 100 |
| Outside Diameter (cm) | 102 |
| Outside Diameter (in) | 4 |
| Outside Diameter (mm) | 10.2 |
| Overall Height (cm) | 11.4 |
| Overall Height (in) | 4.5 |
| Overall Height (mm) | 11.4 |
| Weight (kg) | 0.64 |
| Weight (lb) | 1.4 |
