Description
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- External valve access allows for easy servicing and online replacement to minimize downtime
UPC Product: 00633955376694 Family Code: FAMCPP Unit of Measure: EA Height: 40.8 IN |103.632 CM Length: 21.6 IN |54.864 CM Width: 19.2 IN |48.768 CM Volume: 9.79 FT3 |.277 M3 Chargeable Weight: 112 LBS | 50.8 KG
Technical Specifications
| Convertible | Non-Convertible |
|---|---|
| Fluid Inlet Size (in) | 3/4 |
| Fluid Inlet Size (mm) | 19.05 |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 3/8 |
| Fluid Outlet Size (mm) | 9.525 |
| Fluid Outlet Thread Type | NPT |
| Hose Inlet Diameter (cm) | 0.5 |
| Hose Inlet Diameter (in) | 3/16 |
| Hose Inlet Diameter (mm) | 5 |
| Includes | 仅适用于泵的空气控制器, ポンプ用エア制御, Pump Only Air Controls, Controles bombeo solamente de aire, 펌프 에어 제어장치, 喷枪软管, ガンホース, Gun Hose, manguera de la pistola, 건 호스, 吸料软管, 吸引ホース, Suction Hose, manguera de aspiración, 흡입 호스, 流体过滤器, 液体フィルター, Fluid Filter, filtro de fluido, 유체 필터 |
| Maximum Flow Rate (GPM) | 1.6 |
| Maximum Flow Rate (L/min) | 6 |
| Maximum Hose Length (ft) | 25 |
| Maximum Hose Length (m) | 7.5 |
| Maximum Working Pressure (psi) | 2300 |
| Maximum Working Pressure (kPa) | 15900 |
| Power Source | Air |
| Maximum Working Pressure (MPa) | 15.9 |
| Model | Merkur |
| Maximum Working Pressure (bar) | 159 |
| Weight (kg) | 50 |
| Weight (lb) | 111 |
| Pump Type | Pneumatic Piston Pump |
| Type | Airless Spray Package |
| Spray Type | Airless |
| Motor Type | Pneumatic |
| Wetted Material | Stainless Steel, Tungsten Carbide with 6% Nickel, UHMWPE, PTFE, Aluminum, Acetal, Polyethylene, Nylon, Polypropylene, Polyurethane, Solvent-Resistant O-Ring |
| Number of Guns | 1 |
| Pressure Type | High Pressure |
| Mount Type | Cart Mount |
| Gun Technology | Airless |
| Gun Type | Airless |
| Gun Included | 1 |
| Gun Model | XTR5+ |
| Pump Ratio | 23:1 |
| Product Type | Spray Package |
| Technology Type | Airless |
